Huawei smart meter tri DHSU1079-CT

Measurement:

-Compliance with EN 50470-1/-3 standard

-Connection type: 3P4W

-Accuracy: CT: Class C/0.5S

-Constant: CT:6400imp/kWh

Voltage:

-Nominal voltage (Un): 3x220/380V...3×240/415V

-Operating range: 0.8Un ~ 1.15Un

-Power consumption: ≤2W, 10VA

Current: CT, 0.015-1.5(6)A

Frequency: 50Hz or 60Hz

Display Interface:

-7 characters of 7 segment display

-Digital size: 4.3mm×8.9mm

LED Indication: Pluse Output

Communications:

-RS485,Modbus-RTU

-Baud Rate:1200bps, 2400bps,4800bps, 9600bps(default), 19200bps

Measured Values:

-Import/Export kWh, kvarh

-Instantaneous kW, kvar, kVA

-Irms, Vrms, Frequency, Power factor,etc

Environmental:

-Operating Temperature: -25°C to +55 °C

-Storage Temperature : -40 °C to +70 °C

-Relative Humidity: ≤ 95%RH(non-condensing)

-Ingress Protection: IP20

Dimension:

-Dimensions:72mm×100mm× 65mm

-Weight: 0.33 kg (Approx.)
